The rollers are mirror‑finished so that during high‑pressure tow drawing and spreading the fiber damage is minimized to the greatest extent.

The complete line adopts an HMI+PLC control system, enabling easy operation, high production efficiency, and reduced operational complexity.

The entire machine uses gear drive, ensuring strong torque transmission and high stability.

Equipped with an advanced temperature‑control system and surface‑treatment equipment to enhance fiber–resin interfacial bonding.

Widely used for manufacturing high‑strength composite products such as ballistic panels, lightweight structural components, and wear‑resistant liners.

SALIENT FEATURES Of
Aramid & PE UD Prepreg Production Line

UD prepreg is made from UHMWPE or aramid fiber as the substrate. Fibers are evenly spread by advanced high‑tech equipment, impregnated and coated with a high‑strength elastomeric resin and film‑bonded, then laminated in 0°/90° orthogonal layers to form an ultra‑light, high‑strength ballistic material. The product features low density, wear resistance, impact resistance, and excellent cut and puncture toughness.

Our aramid & PE UD prepreg production line integrates advanced automation equipment and intelligent management systems to achieve fully automated production from raw materials to finished products. This high level of automation greatly improves production efficiency and reduces labor costs and ensures stable and consistent product quality. The prepreg production line also offers high flexibility and scalability, allowing rapid adjustment of production schedules and product specifications to meet market and customer needs.

TECHNICAL SPECS Of
Aramid & PE UD Prepreg Production Line

Roller Width	1800mm
Finished Product Width	≤1650mm
Type of Adhesive	Waterborne
Method of Filament Expansion	Mechanical method with multiple rollers
Drive Control	Frequency conversion and servo system
Heating Method	Circulating heat conduction oil
Temperature Control	60KW external temperature controller
Total Power	90KW
Mechanical Speed	5~11m/min
Power Supply	380V/50Hz
